The universal film scanning system
Aperture card scanner
| Compatible film types | Microfiche; jackets; jumbo fiche; ultrafiche; microcards; 16/35 mm roll microfilm; cartridge (M-type, C-clip); aperture cards; photographic slides; negatives; 35 mm perforated films |
| Image sensor | 18 MP ultra-high resolution area array with real-time on-screen view |
| Lens Optics | Production-level, high-end customized lens developed specifically for microform clarity |
| Capture mode | Grayscale or bi-tonal, color |
| Capture time |
1/3 second per image |
| Reduction ratio |
7x to 105x |
| Scan area |
max. 35 mm x 47 mm / 2.38 x 1.85 inches (on film) |
| Output resolution | 100 – 2400 dpi |
| Scan options | Scan to CD/DVD, file, network, USB, print, email, Cloud, Google Docs, Dropbox |
| Focus adjustment | automatic and manual |
| Sensor optimization | included, fully adjustable optical image rotation |
| Zoom adjustment | motorized (optical) and digital |
| File formats | TIFF (raw, compressed, single or multi); PDF (single, multi-page); JPEG; JPEG 2000; BMP; GIF; PNG |
| Integrated USB output | Two built-in USB 3.0 ports / flash-drive ports (with backward compatibility) |
| Standard components |
Touchscreen-compatible software; manual and motorized roll film pods; smart edit; opaque microcard LED; 3M adapter; RapidScan Batch Scanning |
| Scanner options | Vendor interface kit; OCR and Annotation |
| Light source | Custom-calibrated LED array |
| Security | integrated Kensington lock slot |
| Interface |
USB 3.0 |
| Operating system | Windows 7 Professional (64 bit only); Windows 8 (64 bit only) Intel Processor; WIN 10 PRO (64 bit), further alternatives on request |
| Dimensions | (w x d x h) 450 mm x 515 mm x 230 mm 17.7 x 20.3 x 9.1 inches |
| Work Space (Footprint) | (w x d) 305 x 515 / 12 x 20.3 inches |
| Weight | 7.2 kg / 16 lbs |
Aperture card scanner
High performance roll film scanning.
|
|
High performance roll film scanning.
Load and go operation.
An easy film transport path and intuitive software makes loading, scanning and rewinding a simple process.
Quantum software.
The OM Mini uses the Quantum software suite for image capture and processing. QuantumScan offers precise framing technology for accurate front-end capture. QuantumProcess offers extensive editing options to meet the exact image and file specifications needed for output.
External PC.
An included external PC ensures maximum flexibility, efficiency and minimized downtime. For added portability and space economy, the OM Mini is also available with a laptop option.
Stackable.
Boasting the smallest footprint of any production scanner on the market, the space-saving design of the OM Mini allows operators to command multiple scanners at once for increased throughput and greater return on investment without an increase in physical requirements.
Portable.
The OM Mini is ideal for end-users with multiple branches or with projects in different locations. Economically-sized, it can be safely transported commercially or personally in a protective carrying case.
Digital genius – the microfiche scanner with automatic loading system.
|
|
